Electromagnetic Flow Meter (Integrated Display)

  • Line Size
    15 mm to 300 mm.
  • Process Pressure
    10 kg/cm²
  • Process Temp.
    PTFE – 150°c Rubber – 85°c
  • Electrode MOC
    SS 316 Hastelloy C
  • Internal Lining
    PTFE / Rubber
  • Display Version
    Integrated
  • Measuring Tube Material
    SS 316
  • Connection
    Flange ANSI 150

India’s Leading Electromagnetic Flow Meter Manufacturer And Supplier

Arrowmech Instruments & Automation offers the AEFM-100 Electromagnetic Flow Meter, a microcontroller-based full-bore type specially designed for various industrial applications. Our flow meter provides precise measurements of conductive liquids and slurries in closed pipes. Unlike traditional mechanical flow meters, its simple and rigid design ensures maintenance-free operation, making it a hassle-free choice for accurate flow measurement. The use of advanced technology provides the highest reliability and better measuring accuracy, delivering electrical signals such as 4-20 mA DC, Pulse, and RS 485 linearly proportional to the volumetric flow.

Arrowmech is recognized as India's leading supplier of Electromagnetic Flow Meters. We are renowned for our top-quality Electromagnetic Flow Meters, offering various sizes, materials, and liner materials to suit the diverse requirements of our users.

The Electromagnetic Flow Meter is widely used for measuring the flow of conducting fluids. It is suitable for applications such as drinking water, wastewater, dirty liquids, raw water, and more. The sensor operates on Faraday's Law of Electromagnetic Induction and is compact and sensitive. Options for an earth ring or earth electrode are available, and the sensor complies with IP68 standards, ensuring durability.

The unique feature of the Electromagnetic Flow Meter is its full-bore flow, which means it does not obstruct the flow of the liquid being measured, resulting in no pressure drop and more accurate results. The AEFM-100 by Arrowmech Instruments & Automation is a revolutionary solution for industrial flow measurement, offering precise measurements with its cutting-edge technology, multiple information displays, and various output options for seamless integration with existing systems.

  • Measuring Range
    0.2 to 12 m/s (Bidirection)
  • Accuracy
    0.5% (0.2% Contact Us).
  • Repeatability
    ±1% of span.
  • Display
    LCD Multiple Info.
  • Measuring Units
    Selectable : KG/H, M³/H, L/H,L/M, L/S, KG/M, KG/S
  • Output
    4 ~ 20 mA, RS 485, Pulse.
  • Power Supply
    80 ~ 240 V A.C. / 24 V D.C.
  • Protection Class
    IP 67 (Transmitter).
  • Remote Display
    10m Cable.
  • Processor
    ARM Microprocessor.
  • Conductivity
    10 µS/cm
  • Response Time
    0.3 Seconds.
  • Empty Pipe Detection
    yes
  • Environment Temperature
    0°c to 55°c
  • Electronics Housing
    Die Cast Alluminium (IP 65)

Features Of Integrated Electromagnetic Flow Meter

Precise Measurement

Our flow meter employs magnetic coils and electrodes to deliver highly accurate measurements of fluid flow, ensuring precise control over industrial processes.

Wide Measuring Range

With a bidirectional measuring range from 0.2 to 12 m/s, our flow meter accommodates a broad spectrum of flow rates, making it suitable for diverse applications.

High Accuracy

Offering an accuracy of 0.5%, our electromagnetic flow meter provides reliable and trustworthy measurements, vital for maintaining process efficiency and minimizing wastage.

Durable Construction

Designed to withstand harsh environments, our flow meter features a robust build capable of handling extreme temperatures, pressure, and corrosive substances, ensuring long-term performance with minimal maintenance.

Multiple Display Options

Our flow meter offers various display options, allowing users to choose the most convenient way to view flow data, enhancing user experience and simplifying data interpretation.

Versatile Output Options

Supporting multiple output options, including 4~20mA, RS485, and Pulse outputs, our flow meter seamlessly integrates with other control and monitoring systems, enabling efficient data transfer and process automation.

Fast Response Time

With a quick response time, our flow meter promptly detects and responds to changes in flow rates, crucial for maintaining process stability and promptly identifying anomalies.

Wide Operating Temperature Range

Operating in temperatures from 0°C to 55°C, our flow meter is suitable for various industrial environments, ensuring reliable performance in diverse conditions.

Empty Pipe Detection

Our electromagnetic flow meter includes features such as empty pipe detection, alerting users to no flow in the pipe, preventing inaccurate readings, and enhancing overall usability and reliability.
